Hull MA Crossover Band //@version=5
indicator("Hull MA Crossover Band", overlay=true)
// Inputs
src = input.source(close, title="Source")
length = input.int(55, title="Hull MA Length")
smoothing = input.int(3, title="Smoothing Length") // Additional smoothing to narrow bandwidth
// Function: Hull Moving Average (HMA) Calculation
HMA(_src, _length) =>
ta.wma(2 * ta.wma(_src, _length / 2) - ta.wma(_src, _length), math.round(math.sqrt(_length)))
// Calculate Hull MA with additional smoothing
hullMA = HMA(src, length)
smoothedHullMA = ta.sma(hullMA, smoothing) // Applying extra smoothing for stability
// Define color based on position of candle relative to the Hull MA
hullColor = close > smoothedHullMA ? color.green : color.red
// Plot the Hull MA band with color indicating position of price
plot(smoothedHullMA, color=hullColor, linewidth=2, title="Hull MA Band")
