Adaptive CE-VWAP Breakout Framework [KedArc Quant]

📘 Description

A structured framework that unites three complementary systems into one charting engine:

>Chandelier Exit (CE) – ATR-based trailing logic that defines trend direction, stop placement, and risk/reward overlays.
>Swing-Anchored VWAP (SWAV) – a dynamically anchored VWAP that re-starts from each confirmed swing and adapts its smoothness to volatility.
>Pivot S/R with Volume Breaks – confirmed horizontal levels with alerts when broken on expanding volume.

This script builds a single workflow for bias → trigger → management>without mixing unrelated indicators. Each module is internally linked rather than layered cosmetically, making it a true analytical framework—not.


🙏 Acknowledgment

Special thanks to Dynamic Swing Anchored VWAP by Zeiierman, whose swing-anchoring concept inspired a part of the SWAV module’s implementation and adaptation logic.
Support and Resistance Levels with Breaks by LuxAlgo for S/R breakout logic.


🎯 How this helps traders

>Trend clarity – CE color-codes direction and provides evolving stops.
>Context value – SWAV traces adaptive mean paths so traders see where price is “heavy” or “light.”
>Action filter – Pivot+volume logic highlights true structural breaks, filtering false moves.
>Discipline tool – Optional R:R boxes visualize risk and target zones to enforce planning.



🧩 Entry / Exit guidelines (for study purposes only)

Bias Use CE direction: green = long bias · red = short bias

Entry

1. Breakout method>– Trade in CE direction when a pivot level breaks on valid volume.
2. VWAP confirmation>– Prefer breaks occurring around the nearest SWAV path (fair-value cross or re-test).

Exit

>Stop = CE line / recent swing HL / ATR × (multiplier)
>Target = R-multiple × risk (default 2 R)
>Optional live update keeps SL/TP aligned with current CE state.

🧮 Core formula concepts

>ATR Stop: `Stop = High/Low – ATR × multiplier`
>VWAP calc: `Σ(price × vol) / Σ(vol)` anchored at swing pivot, adapted by APT (Adaptive Price Tracking) ratio ∝ ATR volatility.
>Volume oscillator: `100 × (EMA₅ – EMA₁₀)/EMA₁₀`; valid break when > threshold %.

⚙️ Input configuration (high-level)

Master Controls
• Show CE / SWAV modules • Theme & Fill opacity

CE Section
• ATR period & multiplier • Use Close for extremums
• Show buy/sell labels • Await bar confirmation
• Risk-Reward overlay: R-multiple, Stop basis (CE/Swing/ATR×), Live update toggle

SWAV Section
• Swing period • Adaptive Price Tracking length • Volatility bias (ATR-based adaptation) • Line width

Pivot & Volume Breaks
• Left/Right bar windows • Volume threshold % • Show Break labels and alerts

⏱ Best timeframes

>Intraday: 5 m – 30 m for breakout confirmation
>Swing: 1 h – 4 h for trend context
Settings scale with instrument volatility—adjust ATR period and volume threshold to match liquidity.

📘 Glossary

>ATR: Average True Range (volatility metric)
>CE: Chandelier Exit (trailing stop/trend filter)
>SWAV: Swing-Anchored VWAP (anchored mean price path)
>Pivot H/L: Confirmed local extrema using left/right bar windows
>R-multiple: Profit target as a multiple of initial risk

💬 FAQ

Q: Does it repaint? A: No—pivots wait for confirmation and VWAP updates forward-only.
Q: Can modules be disabled? A: Yes—each section has its own toggle.
Q: Can it trade automatically? A: This is an indicator/study, not an auto-strategy.
Q: Is this financial advice? A: No—educational use only.

⚠️ Disclaimer

This script is for educational and analytical purposes only.
It is not financial advice. Trading involves risk of loss. Past performance does not guarantee future results. Always apply sound risk management.
